LM-T Releasing Spear can catch the drill pipe, tubing and casing from those tools' internal diameter. The releasing spear can be assembled with fishing spear packer, internal cutters, upper fishing jar and jar accelerator under different operation situation. If the fish cannot be pulled, the spear can be easily be released and disengaged.
| Specifications-Releasing Spear LM-T | ||||
| Model | Nut QD. (mm) | C^tchsue (in) | LD (mm) | Code |
| MT48 | 35 | 1£ | 8 | LQ2-100 |
| LM-T60 | 45 | 2 3/8 | 8 | LQ2-110 |
| LM-T73 | 54 | 2 7/8 | 10 | L02-120 |
| LM-T89 | 66 | 31/2 | 10 | LQ2-130 |
| LM-T 102 | 76 | 4 | 16 | LQ2-140 |
| LM-T114 | 88 | 4 1/2 | 16 | L02-150 |
| LM-T127 | 96 | 5 | 25 | LQ2-160 |
| LM-T 140 | 108 | 51/2 | 30 | L02-170 |
| LM-T 168 | 130 | 65/8 | 30 | LQ2-180 |
| LM-T178 | 145 | 7 | 50 | LQ2-190 |
| LM-T219 | 174 | 85/8 | 71 | LQ2-210 |
| LM-T245 | 174 | 95m | 71 | L02-220 |
| LM-T273 | 210 | 10 3/4 | 71 | L02-230 |
| LM-T273-1 | 222 | 10 3/4 | 71 | L02-260 |
| LM-T340 | 210 | 13 3/8 | 71 | LQ2-250 |
| LM-T340-1 | 222 | 13 3/8 | 71 | LQ2-240 |
| Specifications-Releasing Spear LM/B | ||||
| Model | NutO.D. (mm) | Catch size (in) | LD<nvn) | Code |
| LM-T48-B | 35 | 1.9 | 8 | L02-4810 |
| LM-T60-B | 47 | 2 3/8 | 10 | L02-6010 |
| LM-T73-B | 58 | 2 7/8 | 10 | L02-7310 |
| LM-T89-B | 71 | 3 1/2 | 12 | L02-8910 |
| LM-T102-B | 82 | 4 | 16 | L02-10210 |
| LM-T114-B | 92 | 4 1/2 | 19 | L02-11410 |
| LM-T127-B | 98 | 5 | 22 | L02-12710 |
| LM-T140-B | 108 | 5 1/2 | 25 | L02-14010 |
| LM-T168-B | 130 | 6 5/8 | 25 | 102-16810 |
| LM-T178-B | 145 | 7 | 50 | L02-17810 |
| LM-T219-B | 174 | 8 5/8 | 71 | L02-21910 |
| LM-T245-B | 174 | 9 5/8 | 71 | L02-24510 |
| LM-T273-B | 210 | 10 3/4 | 71 | L02-27320 |
| LM-T273-B1 | 222 | 10 3/4 | 71 | L02-27330 |
| LM-T340-B | 210 | 13 3/8 | 71 | L02-34020 |
