  • Q680(5W175B)Quintuplex Plunger / Piston Pump

Q680(5W175B)Quintuplex Plunger / Piston Pump

The Saigao Model Q680 is a single acting quintuplex plunger / piston pump rated at 680 HP in continuous duty services. This versatile pump is offered with a variety of material and design options that make it ideal for general industrial, reverse osmosis, and typical applications involved in the production of oil and natural gas.












Technical Specifications of Q680(5W175B)Quintuplex Plunger / Piston Pump:

Specifications


English Units

Metric Units


Continuous

Intermittent

Stroke Length


175 mm

Rated bhp

650 HP


Rated Rod Load

26015 lb

11800 Kg

Maximum Speed

266 rpm


Pump Weight

8157 lb

3900 Kg

Minimum Speed

90 rpm

75 rpm

Oil Capacity

44 gal

165 L

Max. plunger size x stroke length.

140x175mm

Max. Fluid Temp

284 °F

140 °C

Crankshaft extension Dia.x length

140x280 mm

Mechanical Efficiency


90%

Keyway (width x depth x length)

36x12x270 mm


Performance Ratings of Q680(5W175B)Quintuplex Plunger / Piston Pump:

(Volumes indicated are displacement of incompressible fluid)

plunger Dia.

L/RPM

Gal/RPM

Max.Press.

pump speed=90RPM

pump speed=150RPM

pump speed=200RPM

pump speed=266RPM

pump speed=288RPM

mm

in

Mpa

Psi

LPM

GPM

M3/h

LPM

GPM

M3/h

LPM

GPM

M3/h

LPM

GPM

M3/h

LPM

GPM

M3/h

43

1.69

1.270

0.336

80.0

11600

114

30.2

6.9

190.5

50.3

11.4

254.0

67.1

15.2

337.8

89.2

20.3

365.8

96.6

21.9

48

1.89

1.583

0.418

63.0

9135

142

37.6

8.5

237.4

62.7

14.2

316.5

83.6

19.0

421.0

111.2

25.3

455.8

120.4

27.3

54

2.13

2.003

0.529

50.0

7250

180

47.6

10.8

300.4

79.4

18.0

400.6

105.8

24.0

532.8

140.7

32.0

576.8

152.4

34.6

61

2.40

2.556

0.675

40.0

5800

230

60.8

13.8

383.4

101.3

23.0

511.2

135.0

30.7

679.9

179.6

40.8

736.1

194.5

44.2

68

2.68

3.176

0.839

32.0

4640

286

75.5

17.2

476.4

125.9

28.6

635.2

167.8

38.1

844.8

223.2

50.7

914.7

241.6

54.9

77

3.03

4.072

1.076

25.0

3625

367

96.8

22.0

610.9

161.4

36.7

814.5

215.2

48.9

1083.3

286.2

65.0

1172.9

309.8

70.4

86

3.39

5.080

1.342

20.0

2900

457

120.8

27.4

762.0

201.3

45.7

1016.0

268.4

61.0

1351.3

357.0

81.1

1463.1

386.5

87.8

96

3.78

6.330

1.672

16.0

2320

570

150.5

34.2

949.5

250.8

57.0

1266.0

334.5

76.0

1683.8

444.8

101.0

1823.1

481.6

109.4

109

4.29

8.161

2.156

12.5

1813

734

194.0

44.1

1224.1

323.4

73.4

1632.2

431.2

97.9

2170.8

573.5

130.2

2350.3

620.9

141.0

122

4.80

10.223

2.701

10.0

1450

920

243.1

55.2

1533.5

405.1

92.0

2044.7

540.1

122.7

2719.4

718.4

163.2

2944.4

777.8

176.7

137

5.39

12.892

3.406

8.0

1160

1160

306.5

69.6

1933.8

510.9

116.0

2578.4

681.1

154.7

3429.3

905.9

205.8




152.4

6.00

15.953

4.214

6.3

914

1436

379.3

86.1

2393.0

632.2

143.6

3190.6

842.9

191.4







Brake Horsepower Required

230.4

384

512.1

681.0(Continuous work)

737.4


*Flows are based on 100% volumetric efficiency. Brake Horsepower /Kilowatts Required is based on 90% Mechanical Efficiency.Consult Saigao for continuous service speeds in excess of 288 RPM.

Not all plunger sizes are shown, Additional plunger sizes are available.Please contact Saigao for more details. Standard configuration is a single extended crank, double extending crankshaft please contact Saigao.

Discharge and Suction Connection mode and size please contact Saigao.
