Name: TSJ2600/660 Drilling Rig
Brand: SHANDONG SAIGAO GROUP CORPORATION

Structure Features

1.Mechanical transmission, rotary table rotation, low center of gravity, smooth transmission, strong and durable, reliable operation, good sealing
2.Reasonable structure for easy maintenance and repair
3.Available to match with cathead device to tighten and loosen drilling tools

Technical Specifications of TSJ2600/660 Drilling Rig

Drilling depth（drill pipe φ89mm）（m）		1500～2600
Drift dia. of Rotary table （mm）		φ660
Speed of rotary table（Forward/ Reverse） (r/min)		45 64 103 178
Max output torque of rotary table (KN.m)		25
Max single rope hoisting capacity of winch (KN)		100
Hoisting speed of winch (m/s)		1.0 2.26 3.9
Input rotate speed of clutch (r/min)		901
Traveling system		5×6
Motor unit	Diesel	SC7H250D2-YM 185kW
	Motor	Y315S-4 160kW
Overall dimensions (mm)		4477×2288×1290
Weight (Exclude power) (kg)		9100
